Features
|
|
NEGATIVE SIZE: 24 X 36 mm or 18 X 24 mm (half size) selectable at will
FILM USED: 35 millimeter film pre-loaded in safety cartridge STANDARD LENS: HEXANON f/1.4, f = 57mm, 6 elements in 5 groups, or HEXANON f/1.8, f = 52 mm, 6 elements in 5 groups, minimum focusing distance 0.45 meter (1.5 ft.) LENS MOUNT: Bayonet type KONICA MOUNT Model II, 47 mm diameter, 40.5 mm flange back APERTURE MECHANISM: Full automatic (automatic full aperture return) with manual control for depth of field check SHUTTER: COPAL SQUARE, B. 1 to 1/1000 Sec. Equidistant steps in multiples of 2. Cross-couples with slip-on KONICA LIGHT METER III. "M" and "X" synchroflash settings electronic flash synchronization up to 1/125 Sec. at "X" setting. Self timer VIEWFINDER: Eye level, reflex view finding utilizing pentaprism. Microdaprism center focusing spot. Half-frame indication marks in viewing frame COCKING LEVER: Single stroke, thumb-operated cocking lever for simultaneous shutter cocking and film wind, mirror and automatic aperture re-set. 190º swing, 10º free play FILM COUNTER: Automatic sequential counter, self re-setting upon back lid operation FILM REWIND: Folding crank rewind. Rewind button self re-setting upon operation of cocking lever FILTERS: Screw-in type frame, 55 mm screw of 0.75 mm pitch LENS HOOD: Screw-in type, 55 mm diameter DIMENSIONS & WEIGHT: With f/1.8 lens: 145.5 (w) X 94.5 (h) X 88.5 mm (t), 890 grams With f/1.4 lens: 145.5 (w) X 94.5 (h) X 89.5 mm (t), 970 grams |
