NEGATIVE SIZE: 24 X 36 mm or 18 X 24 mm (half size) selectable at will
FILM USED: 35 millimeter film pre-loaded in safety cartridge
STANDARD LENS: HEXANON f/1.4, f = 57mm, 6 elements in 5 groups,
or HEXANON f/1.8, f = 52 mm, 6 elements in 5 groups, minimum
focusing distance 0.45 meter (1.5 ft.)
LENS MOUNT: Bayonet type KONICA MOUNT Model II, 47 mm
diameter, 40.5 mm flange back
APERTURE MECHANISM: Full automatic (automatic full aperture return) with
manual control for depth of field check
SHUTTER: COPAL SQUARE, B. 1 to 1/1000 Sec. Equidistant steps in multiples of 2.
Cross-couples with slip-on KONICA LIGHT METER III.
"M" and "X" synchroflash settings electronic flash
synchronization up to 1/125 Sec. at "X" setting. Self timer
VIEWFINDER: Eye level, reflex view finding utilizing pentaprism. Microdaprism
center focusing spot. Half-frame indication marks in viewing frame
COCKING LEVER: Single stroke, thumb-operated cocking lever for
simultaneous shutter cocking and film wind, mirror and automatic
aperture re-set. 190º swing, 10º free play
FILM COUNTER: Automatic sequential counter, self re-setting upon back lid operation
FILM REWIND: Folding crank rewind. Rewind button self re-setting upon
operation of cocking lever
FILTERS: Screw-in type frame, 55 mm screw of 0.75 mm pitch
LENS HOOD: Screw-in type, 55 mm diameter
DIMENSIONS & WEIGHT: With f/1.8 lens: 145.5 (w) X 94.5 (h) X 88.5 mm (t),
890 grams
With f/1.4 lens: 145.5 (w) X 94.5 (h) X 89.5 mm (t), 970 grams
